AA59832/7
Slot width. The available slot widths needed to accommodate various printed board thicknesses for the extractors
covered by this CID specification sheet are specified in table II. The slot width designator shall be included in the
PIN.
TABLE II. Slot width configurations and dimensions. 1/
Slot width
Slot width
Accommodates printed
Roll pin
Handle width
designator
dimension "A"
board thickness
width
dimension "B"
2/
2/
Inch (mm)
Inch (mm)
Inch (mm)
Inch (mm)
1
.040 (1.02)
.032 (0.8)
.187 (4.75)
2
.075 (2.03)
.063 (1.6)
.187 (4.75)
.25 (6.4)
3
.105 (2.79)
.094 (2.4)
.250 (6.35)
4
.142 (3.56)
.125 (3.2)
.250 (6.35)
.29 (7.4)
5
.165 (4.19)
.156 (4.0)
.312 (7.94)
1/
Dimensions are in inches. Millimeters, in parenthesis, are given for general information only.
2/
Material. The material used in the extractor body shall be as specified in AA59832. The applicable material type
designators for this CID specification sheet are "1" (aluminum alloy 6061, temper T6), "2" (aluminum alloy 5052,
temper H32), or "7" (Stainless steel, type 301, 302 or 304). The material designator shall be included in the PIN.
Material thickness. The aluminum thickness shall be .063 ±.003 inch (1.60 ±0.076 mm). The stainless steel
thickness shall be .060 ±.002 inch (1.58 ±0.05 mm).
Roll pin. A stainless steel roll pin is furnished with each extractor. The roll pin is .09375 inch (2.38 mm) diameter by
the lengths specified in table II.
Finish. The finish designator shall be as specified in AA59832. The finishes available for this CID specification
sheet are as follows: "A" (anodize) or "L" (low resistance chemical film) for extractors fabricated of aluminum alloys
and "P" (passivation treatment) extractors fabricated of stainless steel.
Color. The color designator shall be as specified in AA59832. The colors available for this CID specification sheet
shall be "C" (clear) or "G" (gold) for low resistance chemical film and "C" (clear) for passivation treatment. The color
of anodized extractors shall be specified in table III. The color designator shall be included in the PIN.
TABLE III. Colors of anodized extractors.
Designator
Color
Designator
Color
B
Black
R
Red
C
Clear
U
Blue
D
Green
V
Violet (purple)
E
Gray
W
Brown
F
Orange
Y
Yellow
2
