[INCHPOUND]
AA59832/8
18 November 2014
COMMERCIAL ITEM DESCRIPTION
SPECIFICATION SHEET
EXTRACTOR, ELECTRICAL CARD, METAL, NONLOCKING, SINGLESIDED ACTUATION,
NARROW PROFILE, STRAIGHT ACTUATING HANDLE, WITH RELEASE TAB,
FOR .032, .063, .094, .125, AND .156 INCH THICK CIRCUIT CARD ASSEMBLIES
The General Services Administration has authorized the use of this
commercial item description for all federal agencies.
The complete requirements for procuring extractors described herein shall consist of this document and the latest
issue in effect of AA59832.
CLASSIFICATION/PART IDENTIFICATION NUMBER (PIN). This commercial item description (CID) specification
sheet uses a classification system which is included in the Part Identification Number (PIN) as shown in the following
example (see NOTES herein).
AA59832
/08
*
*
*
*
*
│
│
│
│
│
│
│
│
│
│
│
│
│
│
│
│
│
│
│
│
│
────┴────
────┴────
────┴────
───┴───
───┴───
───┴───
────┴────
CID number
Applicable
CID sheet
(see table I)
(see table II)
(see table III)
Example: AA59832/08S21AY is the PIN for a right handed, straight handle with release tab, aluminum (alloy 6061)
extractor designed for mounting on a circuit card assembly with a printed board thickness of .063 inch (1.60 mm) in
width. The corrosion protection finish is yellow anodize with a contrasting color SED symbol on the handle.
SALIENT CHARACTERISTICS.
Performance. Extractors shall be capable of initiating the removal of a circuit card assembly from its installed
position. The mechanical advantage of all extractor configurations on this CID specification sheet is approximately
4.2:1.
Interface and physical dimensions. The extractors supplied to this CID specification sheet shall be as specified
herein and meet the general requirements specified in CID AA59832.
Configuration. The configuration of an extractor shall be as specified in table I and on figures 1 through 6.
TABLE I. Configurations.
Configuration
Applicable figures
Extractor description
K
Left hand with SED symbol on the straight handle
L
Left hand with straight handle
M
Left hand with bent leg and straight handle
N
Left hand with bent leg and SED symbol on the straight handle
P
Right hand with bent leg and SED symbol on the straight handle
Q
Right hand with bent leg and straight handle
R
Right hand with straight handle
S
Right hand with SED symbol on the straight handle
AMSC N/A
FSC 5998
