MIL-DTL-62738A(AT)
TABLE II. Verification methods.
Title
Requirement
Verification
Design, materials & manufacturing
3.2
4.2
processes
Operating requirements
3.3
4.2.3
Input power
3.3.1
4.2.3.1
Logic levels
3.3.2
4.2.3.2
PWA set up
3.3.3
4.2.3.3
Input peak limiting
3.3.4
4.2.3.4
Point voltage output signal
3.3.5
4.2.3.5
Ignition signal output
3.3.6
4.2.3.6
Ignition inhibit
3.3.7
4.2.3.7
Interface requirements
3.4
4.2.4
Overall envelope and interfaces
3.4.1
4.2.4.1
Ownership & support requirements
3.5
4.2.5
Interchangeability
3.5.1
4.2.5.1
Identification marking
3.5.2
4.2.5.2
Operating environment requirements
3.6
4.2.6
Temperature
3.6.1
4.2.6.1
Fungus
3.6.2
4.2.6.2
Shock
3.6.3
4.2.6.3
Vibration
3.6.4
4.2.6.4
4.2.2 Inspection conditions. Unless otherwise specified herein, all inspections shall be
performed under the following standard (room) ambient conditions:
a. Temperature: 77 + 18°F (25 +8°C).
b. Relative humidity: Uncontrolled room ambient.
c. Barometric pressure: Site pressure.
4.2.3 Operating requirements verification.
4.2.3.1 Input power. To determine conformance to 3.3.1, the input current shall be
measured with an ammeter.
4.2.3.2 CMOS logic levels. To determine conformance to 3.3.2, the input and output
CMOS logic levels shall be observed and verified with an oscilloscope.
