MIL-DTL-62741A(AT)
6.6 Changes from previous issue. Marginal notations are not used in this revision to
identify changes with respect to the previous issue due to the extent of the changes.
P1-29
H
IO9/1
L
P1-37
H
0 ns MIN.
0 ns MIN.
L
110 ns MAX.
100 ns MAX.
U7-10
H
L
H= LOGIC LEVEL 1
L= LOGIC LEVEL 0
FIGURE 1. Waveforms to generate U7-10 clock.
P1-30
H
IOA/2
L
H
P1-37
0 ns MIN.
0 ns MIN.
OEN-Q\
L
110 ns MAX.
100 ns MAX.
U7-4
H
L
H= LOGIC LEVEL 1
L= LOGIC LEVEL 0
FIGURE 2. Waveforms to generate U7-4 clock.
