MIL-DTL-62741A(AT)
P1-36
H
0 ns MIN.
MRD\
L
H
P1-30
IOA/2
0 ns MIN.
250 ns MAX.
L
H
U7-11
250 ns MAX.
L
H= LOGIC LEVEL 1
L= LOGIC LEVEL 0
FIGURE 6. Waveforms to generate U7-11 clock.
U24-6,
H
10, 12, 14,
L
4, 2, U16-14,
12
150 ns
MIN.
150 ns MIN.
U7-3
H
L
240 ns MAX.
200 ns MAX.
H
P1-21
HIGH IMPEDANCE OUTPUT
DATA OUT VALID
THROUGH
HIGH IMPEDANCE OUTPUT
L
P1-28
H= LOGIC LEVEL 1
L= LOGIC LEVEL 0
FIGURE 7. Waveforms for reading U24 and U16 buffers.
U16-10,
H
2, 4, 6
L
U6-10, 4, 2, 6
150 ns
MIN.
150 ns MIN.
U7-11
H
L
240 ns MAX.
200 ns MAX.
P1-21
H
THROUGH
HIGH IMPEDANCE OUTPUT
DATA OUT VALID
HIGH IMPEDANCE OUTPUT
P1-28
L
H= LOGIC LEVEL 1
L= LOGIC LEVEL 0
FIGURE 8. Waveforms for reading U16 and U6 buffers.
19
