MIL-DTL-62739A(AT)
H
IOC/4
0 ns
0 ns
P1-32
MIN.
L
MIN.
H
OEN-Q
260 ns MIN.
P1-38
L
0 ns
MIN.
H
BUS 0-7
VALID DATA
150 ns MIN.
P1-21 THRU 28
L
H= LOGIC LEVEL 1
L= LOGIC LEVEL 0
FIGURE 3. Waveforms for writing data to U3.
H
IOB/3
0 ns
0 ns
P1-31
MIN.
L
MIN.
H
OEN-Q
260 ns MIN.
P1-38
L
0 ns MIN.
H
BUS 0-7
150 ns MIN.
VALID DATA
P1-21 THRU 28
L
H= LOGIC LEVEL 1
L= LOGIC LEVEL 0
FIGURE 4. Waveforms for writing data to U4.
16
