MIL-DTL-62736A(AT)
3.3.8.3 Frequency select latch. The frequency select latch shall be selected by using the
data in table X and applying the waveforms of figure 2. The data in table XI shall then be latched
into U7 by applying the waveforms in figure 5 and the results shown in table XI shall be observed
at U7 pins 2, 7, and 10.
TABLE X. Data to select the frequency select latch.
P1-
28
27
26
25
24
23
22
21
X
X
X
X
0
1
0
0
(X denotes a don't care condition)
3.3.8.4 Frequency select. After selecting U7 by applying the waveforms in figure 2 with
the data in table X, the waveforms shown in figure 5 shall be applied to latch the data shown in
table XII into U7. The frequencies shown in the table shall be observed at U6 pin 5.
TABLE XI. Frequency select latch data.
Applied data
Observed data
P1-
U7 pin
28
27
26
25 24 23
22
21
10
7
2
X
X
X
X
X
0
0
0
0
0
0
X
X
X
X
X
0
0
1
0
0
1
X
X
X
X
X
0
1
0
0
1
0
X
X
X
X
X
0
1
1
0
1
1
X
X
X
X
X
1
0
0
1
0
0
X
X
X
X
X
1
0
1
1
0
1
X
X
X
X
X
1
1
0
1
1
0
X
X
X
X
X
1
1
1
1
1
1
(X denotes a don't care condition)
TABLE XII. Frequency select data.
Applied data
P1-
Observed data
28
27
26
25 24
23
22
21
Frequency at U6 pin 5
X
X
X
X
X
0
0
0
307.20 kHz + 307 Hz
X
X
X
X
X
0
0
1
153.60 kHz + 154 Hz
X
X
X
X
X
0
1
0
76.800 kHz + 77 Hz
X
X
X
X
X
0
1
1
38.400 kHz + 38 Hz
X
X
X
X
X
1
0
0
19.200 kHz + 19 Hz
X
X
X
X
X
1
0
1
9.6000 kHz + 10 Hz
X
X
X
X
X
1
1
0
4.8000 kHz + 5 Hz
X
X
X
X
X
1
1
1
2.4000 kHz + 2 Hz
(X denotes a don't care condition)
